Flow Torch™ 800
The Flow Torch™ 800 is an open coil air heater designed for high flow rates at low pressure drop due to its efficient design with minimal flow restrictions. The robust construction of this 8” diameter stainless steel heater offers reliable long-life performance and reduced operational cost.
The Flow Torch™ 800 incorporates a spiral wound element of the highest grade material, providing quick heat up and cool down cycles with maximum heat transfer.
The Flow Torch™ 800 is capable of operating with airflow of 2000 SCFM and a maximum operating pressure of 3 PSIG*. Maximum output temperature is 482°C (900°F).
All Flow Torch Heaters are UL recognized components under UL file number E365755.
* Note: minor leakage through stranded leads
New! Flanged Fittings!
We have flanges available as a standard option on our Flow Torch heaters. Click here to build your FT400, FT600 & FT800 with flanged inlet and exhaust fittings.
| Max Watt | Max Inlet | Max Exhaust | Min SCFM | Max SCFM | PSIG* |
|---|---|---|---|---|---|
| 75000 W | 250 °F | 900 °F | 76 | 2000 | 3 |
- MountingHorizontal / Vertical
- Heater BodyStainless Steel
- Inlet FittingsStainless Steel
- Exhaust FittingsStainless Steel
Standard power of 2 kW to 75 kW is available for a wide range of applications, including:
- Hot Air Curtains
- Laminating
- Plastic Curing
- Air Drying
- Web Drying
- Metallization
- Baking
- Textile Applications
- Exhaust Gas Heating
- Chemical Processing
- Ink Drying
- Hopper Drying
- Dehumidification
- Paint Baking/Drying
- Sterilization
Control Panels are also available to provide precise temperature regulation.
Additional Information
Pressure Drop Chart (without fittings)
Pressure Drop Chart (with fittings)
Product Fittings
Complete your Thermal System
Check out these upgrade options for the Flow Torch™ 800
Control Panels
Closed-loop heater control systems use a power controller, temperature controller, and thermocouples to monitor and provide constand output temperature.
Insulation Blanket
Our insulation blankets are made specifically for the Flow Torch family of products. Improve safety for people and product, and save money by reducing waste heat.
